OMD-IE3 315M2 200kW 400/690V 50Hz B3
IP23 / Iso F-B / PTC 130? C / PTC 150℃ / AC Heater 230V@50Hz / Shaft 70m6 / Ral 7031 / With Current Insulated NDE Shield
Bouwgrootte: | 315mm |
Vermogen: | 200kW |
Frequentie: | 50Hz |
Polental: | 2 P |
Rotatiesnelheid: | 2950 RPM |
Slip: | 1,67% |
Voltage: | 400/690V |
Aansluiting: | △/Y |
Stroomsterkte: | 338,00/195,14 A |
Rotor voltage: | |
Rotor connectie: | |
Rotor stroom: | |
Rotorblok stroom (Ia/In): | 7% |
Stroom onbelast: | |
Koppel: | 647,5Nm |
Rotorblok koppel (Ma/Mn): | 1,7% |
Koppel limiet (Ma/Mn): | 2,2% |
| Isolatieklasse: | F |
| Temperatuur: | 80K |
| Service factor: | 1 |
| Duty: | S1 |
| Omg. temp.: | -20~40°C |
| Hoogte: | 1000m |
| Bescherming: | IP23 |
| Koeling: | IC01 |
| Montage: | B3,B35,V1 |
| Vibratie: | 2,8mm/s |
| Gewicht: | 1035kg |
| Inertia moment: | 1,713kg/m2 |
| Geluidsniveau: | 90 dB(A) |
| Rotatierichting: | BOTH |
| Start | DIRECT ON LINE |
| Koppel: | DIRECT |
| Belastcurve: | PARABOLIC CURVE |
